Circular Mini DIN Plugs
Plug Components for
Cable Termination
■ Individual components available for cable assembly with overmolding.
■ Plug insulator available with contact positions 3, 4, 5, 6, 7, and 8.
■ Seamless shield case is crimped to cable shield; designed to meet
FCC requirements for EMI/RFI suppression.
■ One-piece shield case - no extra ferrules or shields required with
Cinch Shield Crimp Tools.
■ Contacts are crimp style and supplied on reels.
■ Contacts available with gold over nickel in several options.
■ Tools available to facilitate reliable, efficient termination.
■ Terminates 24 to 30 AWG wire.
■ UL Recognized - file E170218 (UL1977).
Insulation Material: Plug Insulator: 94 V-0 rated nylon
Contact Material: Plug: Phosphor bronze
Contact Plating:
Option 1: Gold flash over nickel underplate overall
Option 2: Option 1 plus additional gold in mating area for
total thickness of 30μin.
Option 3: Option 1 plus additional gold in mating area for
total thickness of 50μin.
Shield Case Material: Steel
Shield Case Plating: Nickel
Dimensions
3-Contact
6-Contact
Call Toll Free: 1 (800) 323-9612
4-Contact
7-Contact
2-60
5-Contact
8-Contact
Marketed exclusively through distribution.
